Characteristics:

HBIN103 has the features of Full digital design, Advanced Acceleration Sensor, Advantaged MEMS & ASIC Technology, Factory calibrated with temperature compensation within full scale, Full linearization compensated, Wide Operating Temperature Range, Easy to Install and Maintain with Low Cost.

• l On both sides of the large LCD display are arrows indicating the direction and degree of horizontal deviation;

• l 0°, 90°, 270°, and 360° special angle location beep tone indicating;

• l Data display turn automatically , data hold function, easy read at any position;

• l Angle data can be sent to a computer or other monitoring&recording equipment with RS232 interface;

• l Calibration & Zero Setting anywhere, anytime if want;

• l Surface colors option or customized.

HBIN103 is a measuring tools and instrumentation widely used in Road Engineering, Construction Works, Industrial Platform and many related fields.

Specifications:

Measuring range          0 ~ 360 ° (each quadrant shows 0 ° to 90 °).

Resolution                  Typical 0.1°(or 0.1%,１ｍｍ/M,１IN/FT).

Absolute Accuracy  Horizontal & Vertical(0°和90°)location: ±0.1°(@２５℃±３℃),

Else(1°～89°) location: ±0.2°(@２５℃±３℃).

Repeatability                   ±0.1° of Full Measuring Range

Temperature drift                  ≤±0.2°(@-5℃～50℃)

Operating Temperature                 -5℃～50℃

Storage Temperature                   -20℃～80℃

Relative Humidity            10~90% RH without coagulated dew

Response Time                         ≤500ms

Stabilization Time                         ≤5s

Power Supply              Layer-built Alkaline Battery: 6F22, 9V×1,

Continuous operating time: ≥8hours.

Power Consumption              ≤100 mW (Backlight off)

Current Drain      When the buzzer does not sound: ≤10mA (Backlight off),

When the buzzer sound: ≤18mA (Backlight off),

Shutdown current: ≤8uA

APO Time            Default: 5 minutes (Customizable)

Housing    Max.size L:166mm,H:60mm,T:25mm, Aluminum alloy, IP65 protection.

Surface Colors       3 optional colors: Orange, Blue, Red, or Customized;

                                  Anodic oxidation coloring.
